Garden Single Arm 10m Q235 Street Lamp Pole With Hot Dip Galvanization

ภาพใหญ่ : Garden Single Arm 10m Q235 Street Lamp Pole With Hot Dip Galvanization

รายละเอียดสินค้า:

Place of Origin:	China
ชื่อแบรนด์:	MilkyWay
ได้รับการรับรอง:	ISO9001/BV/
Model Number:	Street Light Poles

การชำระเงิน:

Minimum Order Quantity:	1 pcs
ราคา:	Negotiation
Packaging Details:	As customer request
Delivery Time:	20 working days after received your payment
Payment Terms:	T/T, L/C at sight
Supply Ability:	300pcs per day

ติดต่อ

รายละเอียดสินค้า

Product Name:	Street Light Poles	Welding standard:	AWS (American Welding Society ) D 1.1
Material:	Q235	Thickness:	1 mm to 36mm
Dimenstion torlance:	+- 2%	Wind Speed:	160 Km/Hour
แสงสูง:	street lighting poles , street lamp pole

Single Arm 10m Q235 Street Light Poles with Hot Dip Galvanization

Specifications:

Place of origin	China
Material	SteelQ235,Q345
Application	Garden, Square, Street, Stadium etc.
Shape of pole	Tapered Round, Shafts are made of steel sheet that folded into required shape and welded by automatic welding machine
Brackets/ Arm	As per customer’s requirement
Wall thickness	2.5mm to 20mm
Welding	Using automatic internal and external double welding makes the welding beautiful in shape. And confirms with international welding standard. .
Base plate mounted	Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customer’s requirement.
Ground mounted	The length buried underground as per customer’s requirement.
Galvanizing	Hot dip galvanization with Chinese standard GB/T 13912-2002 or American standard ASTM A123, IS: 2626-1985.
Powder coating	Pure polyester powder painting, color is optional according to RAL color standard.
Jointing	Jointing of pole with insert mode, face to face joint mode .Every lighting pole has a unique code. All sections belonging to one pole have the same code, so it’s easy to assembly.
Wind Resistance	Against wind pressure of 160Km/h
Earthquake Resistance	Against earthquake of 8 grade
Quality Control	We strictly follow the standard of ISO9001-2008. Quality is in the first place at every stage of production to ensure the product compliance to the specification/standards. Careful inspections are carried out by highly trained inspection engineers during every procedure from raw material stage to finished product and delivery.
Certificates	ISO9001:2008 etc.

Descripition of material:
1. Poles are made by the high-quality metal plants,which were molded into the multi-row cone-shaped vertical steel barwith hot galvanized anti-corrosion treatment
2. Light plate frame is made by high-quality stainless steel
3. Fastened bolts and nuts of stainless steel

Garden Single Arm 10m Q235 Street Lamp Pole With Hot Dip Galvanization 0

Galvanization
Standard:NFA91121
Average thickness of the galvanization:Not less than 86μm.

Garden Single Arm 10m Q235 Street Lamp Pole With Hot Dip Galvanization 1

Company Instruction:

JiangSu Milky Way Steel Poles Co., Ltd.was established in 1988, is located in Yixing City, Jiangsu Province, Wan Shi Town, covering an area of 35,000 square meters, annual output value reached 200 million . We have 20 years experience in design and production. Our main products are power pole, communication towers, street lighting poles, steel bracket and so on. The company has strong technical force, advanced production equipment, perfect quality management system, product quality has reached international advanced level.
