Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel

จีน Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel ผู้ผลิต
Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel ผู้ผลิต Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel ผู้ผลิต Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel ผู้ผลิต

ภาพใหญ่ :  Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel

รายละเอียดสินค้า:

Place of Origin: China
ชื่อแบรนด์: MilkyWay
ได้รับการรับรอง: ISO9001/BV/
Model Number: High Mast Light

การชำระเงิน:

Minimum Order Quantity: 1 pcs
ราคา: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
ติดต่อ
รายละเอียดสินค้า
Product Name: High Mast Light Application: Parking Lot Lighting
Wind Speed: 30m/s Galvanization Thickness: Average 86μm
Thickness: 1 mm to 30 mm Lift time: 50 years
แสงสูง:

mast light tower

,

solar power light pole

 Outdoor Bitumen 3mm 25m High Mast Light with Round Lamp Panel for Parking Lot





 Specifications:



Specification:

20-50 meters high mast pole

Type

high mast pole

Shape

conical, hexagonal and octagonal

Material

Usually   Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,

SS400, SS490ST52

Torlance of dimenstion

-0.02

Design Load in Kg

300~ 1000 Kg appliced to 50cm from the to pole

Surface treatment

Hot dip galvanized Following ASTM A 123, color polyester

power or any other standard by client required.

Standard

Octagonal Conical tapered column
Certified by SIRIM QAS INTERNATIONAL.
Approved by JABATAN KERJA RAYA MALAYSIA.
Conforms to Standard:
Pole design : BS EN 40
Material : BS EN 10025 S275 / JIS G3101 SS400
Welding : BS 5135
Galvanizing : BS 729 / ISO 1461 ASTM A 123

Length of per section

Within 14m once forming without slip joint.

high mast pole suit for

city square,wharf,stadium

Option of high mast pole

Height from 20m to 35m
Flange mounted or planted type

Production Process of high mast pole

Raw material test → Cutting →Molding or bending

→Welidng (longitudinal )→Dimension verify →

Flange welding →Hole drilling →Calibration →Deburr→

Galvanization or powder coating ,painting →Recalibration→

Thread →Packages





 Descripition of material:
 1. Poles are made by the high-quality metal plants,which were molded into the multi-row cone-  shaped vertical steel barwith hot galvanized anti-corrosion treatment
 2. Light plate frame is made by high-quality stainless steel
 3. Fastened bolts and nuts of stainless steel

 Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel 0





 Feature:

 Special designed for stadium to provide high-power, large-  area lighting for facilities; Lighthouse is devided into fixed or lift, fixed poles set up an escalator inside for i  nstallation and maintenance purposes

 Light source :400w-1000w sodium light





 Installation:
 1. high-pressure sodium lamp with external ballast and Triggers installed in light tray.
 2. when replacing or repairing light and other electrical appliances, you should use special wrench to  open it.
 3. control box installed at the poles or the lower part of the poles
 Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel 1




 Specific explanation:
 1.please install according to requirements of the company
 2.make sure that the light body touches the ground during installation.

 Outside Parking Lot Bitumen High Mast Tower 3mm 25m with Round Lamp Panel 2
